| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T05_271T01_9000006604_59186cztM0_level2.fits | modeM0/AS1T05_271T01_9000006604_59186cztM0_level2_quad_clean.evt |
| Size (bytes) | 776,145,600 | 99,979,200 |
| Size | 740.2 MB | 95.3 MB |
| Events in quadrant A | 3,581,697 | 731,813 |
| Events in quadrant B | 3,775,924 | 786,266 |
| Events in quadrant C | 4,310,953 | 695,794 |
| Events in quadrant D | 16,461,700 | 275,622 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16346 | 1 |
| B | 0 | 16718 | 0 |
| C | 0 | 18247 | 0 |
| D | 0 | 54217 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7730 | 27 | 0.349288% |
| B | 7730 | 53 | 0.685640% |
| C | 7730 | 151 | 1.953428% |
| D | 7730 | 4948 | 64.010349% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7730 | 7730 | 24 | 24 | 0.31% | 0.31% |  |
| B | 7730 | 7730 | 40 | 40 | 0.52% | 0.52% |  |
| C | 7730 | 7730 | 114 | 114 | 1.47% | 1.47% |  |
| D | 7730 | 7730 | 5343 | 5343 | 69.12% | 69.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 233 | 157522 | 775.45 | 823 | 800 | 202.1 |
| A | 3 | 245 | 142015 | 698.72 | 823 | 800 | 202.1 |
| A | 10 | 251 | 35963 | 173.98 | 823 | 800 | 202.1 |
| B | 4 | 171 | 250276 | 1420.89 | 818 | 785 | 175.6 |
| B | 0 | 157 | 101907 | 575.9 | 818 | 785 | 175.6 |
| B | 4 | 236 | 90689 | 512.01 | 818 | 785 | 175.6 |
| C | 13 | 3 | 493042 | 2246.28 | 799 | 790 | 219.1 |
| C | 3 | 233 | 353906 | 1611.36 | 799 | 790 | 219.1 |
| C | 9 | 38 | 123328 | 559.17 | 799 | 790 | 219.1 |
| D | 12 | 110 | 12495319 | 67886.78 | 643 | 614 | 184.1 |
| D | 2 | 31 | 404028 | 2191.85 | 643 | 614 | 184.1 |
| D | 11 | 129 | 349293 | 1894.46 | 643 | 614 | 184.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
