| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G07_057T02_9000001504_10398cztM0_level2.evt | modeM0/AS1G07_057T02_9000001504_10398cztM0_level2_quad_clean.evt |
| Size (bytes) | 249,877,440 | 43,369,920 |
| Size | 238.3 MB | 41.4 MB |
| Events in quadrant A | 1,672,839 | 259,829 |
| Events in quadrant B | 1,769,083 | 259,419 |
| Events in quadrant C | 1,652,772 | 259,619 |
| Events in quadrant D | 2,221,338 | 275,063 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18392 | 11006 |
| B | 0 | 20283 | 12744 |
| C | 0 | 19180 | 11774 |
| D | 0 | 22487 | 13398 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 4 |
| B | 0 | 8 | 4 |
| C | 0 | 8 | 4 |
| D | 0 | 7 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 188 | 114 |
| B | 0 | 187 | 104 |
| C | 0 | 188 | 107 |
| D | 0 | 180 | 101 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3601 | 54 | 1.499583% |
| B | 3535 | 56 | 1.584158% |
| C | 3620 | 30 | 0.828729% |
| D | 3880 | 57 | 1.469072% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5013 | 4308 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5013 | 4294 | 1 | 1 | 0.02% | 0.02% |  |
| C | 5013 | 4343 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5013 | 4341 | 3 | 3 | 0.06% | 0.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 31 | 5449 | 55.67 | 430 | 421 | 90.3 |
| A | 0 | 226 | 3971 | 39.3 | 430 | 421 | 90.3 |
| A | 1 | 162 | 3802 | 37.43 | 430 | 421 | 90.3 |
| B | 11 | 51 | 42645 | 515.5 | 420 | 410 | 81.9 |
| B | 4 | 239 | 42575 | 514.65 | 420 | 410 | 81.9 |
| B | 0 | 187 | 16857 | 200.74 | 420 | 410 | 81.9 |
| C | 14 | 234 | 4903 | 45.51 | 420 | 421 | 98.5 |
| C | 8 | 128 | 4171 | 38.08 | 420 | 421 | 98.5 |
| C | 13 | 61 | 3192 | 28.14 | 420 | 421 | 98.5 |
| D | 1 | 52 | 228965 | 2113.25 | 447 | 435 | 108.1 |
| D | 8 | 195 | 108138 | 995.94 | 447 | 435 | 108.1 |
| D | 1 | 20 | 100080 | 921.43 | 447 | 435 | 108.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
