| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C05_001T01_9000003366_22771cztM0_level2.evt | modeM0/AS1C05_001T01_9000003366_22771cztM0_level2_quad_clean.evt |
| Size (bytes) | 253,212,480 | 67,475,520 |
| Size | 241.5 MB | 64.3 MB |
| Events in quadrant A | 1,642,036 | 466,695 |
| Events in quadrant B | 1,571,250 | 467,625 |
| Events in quadrant C | 1,489,327 | 443,785 |
| Events in quadrant D | 2,738,276 | 429,003 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 68 | 0 |
| B | 0 | 68 | 0 |
| C | 0 | 68 | 0 |
| D | 0 | 68 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6783 | 0 |
| B | 0 | 6795 | 0 |
| C | 0 | 6690 | 0 |
| D | 0 | 10372 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3321 | 1 | 0.030111% |
| B | 3322 | 2 | 0.060205% |
| C | 3322 | 8 | 0.240819% |
| D | 3322 | 157 | 4.726069% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3321 | 3321 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3321 | 3321 | 0 | 0 | 0.00% | 0.00% |  |
| C | 3322 | 3322 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3321 | 3321 | 171 | 171 | 5.15% | 5.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 115416 | 1434.95 | 394 | 388 | 80.2 |
| A | 13 | 254 | 5986 | 69.83 | 394 | 388 | 80.2 |
| A | 11 | 47 | 4603 | 52.58 | 394 | 388 | 80.2 |
| B | 0 | 190 | 16898 | 223.32 | 390 | 382 | 74.0 |
| B | 0 | 228 | 13337 | 175.17 | 390 | 382 | 74.0 |
| B | 0 | 230 | 12433 | 162.95 | 390 | 382 | 74.0 |
| C | 14 | 238 | 59659 | 695.42 | 366 | 369 | 85.3 |
| C | 13 | 61 | 2569 | 25.8 | 366 | 369 | 85.3 |
| C | 10 | 22 | 931 | 6.59 | 366 | 369 | 85.3 |
| D | 1 | 52 | 692005 | 7626.01 | 369 | 359 | 90.7 |
| D | 12 | 33 | 294540 | 3243.61 | 369 | 359 | 90.7 |
| D | 12 | 233 | 150033 | 1650.29 | 369 | 359 | 90.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
