| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_001T01_9000004752_32951cztM0_level2.evt | modeM0/AS1C07_001T01_9000004752_32951cztM0_level2_quad_clean.evt |
| Size (bytes) | 103,613,760 | 17,861,760 |
| Size | 98.8 MB | 17.0 MB |
| Events in quadrant A | 431,976 | 120,575 |
| Events in quadrant B | 450,463 | 123,315 |
| Events in quadrant C | 467,265 | 120,911 |
| Events in quadrant D | 1,717,622 | 98,717 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1993 | 2 |
| B | 0 | 2011 | 1 |
| C | 0 | 2131 | 1 |
| D | 0 | 5797 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 996 | 1 | 0.100402% |
| B | 996 | 1 | 0.100402% |
| C | 996 | 6 | 0.602410% |
| D | 996 | 323 | 32.429719% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 996 | 996 | 0 | 0 | 0.00% | 0.00% |  |
| B | 996 | 996 | 0 | 0 | 0.00% | 0.00% |  |
| C | 996 | 996 | 7 | 7 | 0.70% | 0.70% |  |
| D | 996 | 996 | 357 | 357 | 35.84% | 35.84% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 1773 | 68.52 | 111 | 109 | 24.3 |
| A | 3 | 137 | 1060 | 39.16 | 111 | 109 | 24.3 |
| A | 0 | 226 | 995 | 36.49 | 111 | 109 | 24.3 |
| B | 5 | 172 | 6782 | 285.07 | 110 | 107 | 23.4 |
| B | 0 | 229 | 4285 | 178.43 | 110 | 107 | 23.4 |
| B | 12 | 111 | 2565 | 104.97 | 110 | 107 | 23.4 |
| C | 0 | 10 | 47389 | 1786.55 | 105 | 105 | 26.5 |
| C | 7 | 247 | 3261 | 119.24 | 105 | 105 | 26.5 |
| C | 9 | 187 | 2153 | 77.38 | 105 | 105 | 26.5 |
| D | 12 | 227 | 827184 | 31022.83 | 95 | 93 | 26.7 |
| D | 8 | 195 | 241652 | 9060.48 | 95 | 93 | 26.7 |
| D | 7 | 80 | 181910 | 6819.66 | 95 | 93 | 26.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
